Anchor Base with Shackle
Anchor Base with Shackle
Grade: 316 Stainless Steel
Retail and bulk packaging available
The Anchor Base with Shackle includes the hoist anchor base and fixed shackle. It is made from grade 316 stainless steel for maximum corrosion resistance and durability. The Anchor Base is primarily used as a way to attach lifting points to objects with no natural attachments. It features a set screw for securing it to the stud. The shackle has a 180 degree pivoting capability and the base can be secured in the desired position to provide a full range of motion.
Specifications
ALL DIMENSIONS ARE NOMINAL (+/- 3%) AND ARE SUBJECT TO CHANGE WITHOUT NOTICE.
| ITEM | A | B | C (UNC thread) | D | E | F | X | Y | Z | WLL (lb) | WT (lb) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| S0116-HD07 | 0.31″ | 1.00″ | 3/8″-16 | 0.25″ | 0.91″ | 0.79″ | 1.30″ | 2.54″ | 0.75″ | 1,000 | 0.22 |
| S0116-HD08 | 0.38″ | 1.20″ | 7/16″-14 | 0.30″ | 0.99″ | 0.81″ | 1.72″ | 2.92″ | 0.88″ | 1,300 | 0.35 |
| S0116-HD10 | 0.44″ | 1.50″ | 1/2″-13 | 0.38″ | 1.13″ | 1.05″ | 2.02″ | 3.47″ | 1.25″ | 1,500 | 0.78 |
| S0116-HD12 | 0.50″ | 1.56″ | 5/8″-11 | 0.42″ | 1.14″ | 1.14″ | 2.39″ | 3.97″ | 1.38″ | 2,000 | 1.05 |
| S0116-HD13 | 0.63″ | 1.59″ | 3/4″-10 | 0.50″ | 1.47″ | 1.33″ | 2.45″ | 4.22″ | 1.38″ | 3,000 | 1.30 |
| S0116-HD16 | 0.75″ | 1.86″ | 7/8″-9 | 0.63″ | 2.00″ | 1.67″ | 3.02″ | 5.29″ | 1.75″ | 4,000 | 2.64 |
| S0116-HD20 | 0.88″ | 2.00″ | 1″-8 | 0.75″ | 2.48″ | 2.02″ | 3.57″ | 6.11″ | 2.00″ | 6,000 | 3.90 |
| S0116-HD22 | 1.00″ | 2.34″ | 1-1/8″-7 | 0.88″ | 2.78″ | 2.24″ | 4.10″ | 7.16″ | 2.50″ | 8,000 | 7.00 |
| S0116-HD25 | 1.13″ | 2.67″ | 1-1/4″-7 | 0.94″ | 3.00″ | 2.47″ | 4.96″ | 7.75″ | 2.75″ | 10,000 | 8.90 |
