Cast Jaw and Jaw Turnbuckle
Cast Jaw and Jaw Turnbuckle
Grade: 316 Stainless Steel
Thread Type: UNC
Retail and bulk packaging available
The Cast Jaw and Jaw Turnbuckle features an open body and is available in sizes ranging from 3/16″ to 3/4″ to fit every project. These turnbuckles are made from grade 316 stainless steel for maximum corrosion resistance and durability, making them ideal for marine and industrial use.
![Symbol Stamped](https://suncorstainless.com/wp-content/uploads/2021/01/icon_symbol_stamped.png)
![Precision Cast](https://suncorstainless.com/wp-content/uploads/2021/01/icon_precision_cast.png)
![Imported](https://suncorstainless.com/wp-content/uploads/2021/01/icon_import.png)
![Suncor Exclusive](https://suncorstainless.com/wp-content/uploads/2021/01/icon_suncor_exclusive.png)
![Stainless Steel Cast Jaw and Jaw Turnbuckle, S0154-JJ05, S0154-JJ07, S0154-JJ08, S0154-JJ10, S0154-JJ10, S0154-JJ16, S0154-JJ20 Stainless Steel Cast Jaw and Jaw Turnbuckle, S0154-JJ05, S0154-JJ07, S0154-JJ08, S0154-JJ10, S0154-JJ10, S0154-JJ16, S0154-JJ20](https://suncorstainless.com/wp-content/imported/S0154-JJ_Stainless Steel Jaw and Jaw Turnbuckle_Cast.jpg)
Specifications
![Stainless Steel Cast Jaw and Jaw Turnbuckle, S0154-JJ05, S0154-JJ07, S0154-JJ08, S0154-JJ10, S0154-JJ10, S0154-JJ16, S0154-JJ20, Line Drawing Stainless Steel Cast Jaw and Jaw Turnbuckle, S0154-JJ05, S0154-JJ07, S0154-JJ08, S0154-JJ10, S0154-JJ10, S0154-JJ16, S0154-JJ20, Line Drawing](https://suncorstainless.com/wp-content/imported/S0154-JJ_Stainless Steel Cast Jaw and Jaw Turnbuckle_Line Drawing.jpg)
![](https://suncorstainless.com/wp-content/uploads/2024/04/S0154-JJ13.gif)
ALL DIMENSIONS ARE NOMINAL (+/- 3%) AND ARE SUBJECT TO CHANGE WITHOUT NOTICE.
ITEM | A (size) | B | C | D (adjustment) | E | F | G | X | Y | Z | WLL (lb) | WT (lb) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
S0154-JJ05 | 3/16″ | 0.30″ | 0.18″ | 2.50″ | 0.35″ | 7.19″ | 4.81″ | 0.77″ | 5.25″ | 0.47″ | 300 | 0.11 |
S0154-JJ07 | 1/4″ | 0.38″ | 0.22″ | 3.00″ | 0.38″ | 8.63″ | 5.75″ | 0.82″ | 6.26″ | 0.54″ | 440 | 0.21 |
S0154-JJ08 | 5/16″ | 0.40″ | 0.30″ | 4.00″ | 0.38″ | 11.06″ | 7.12″ | 0.90″ | 7.95″ | 0.63″ | 800 | 0.36 |
S0154-JJ10 | 3/8″ | 0.46″ | 0.37″ | 6.00″ | 0.48″ | 16.00″ | 10.00″ | 1.21″ | 11.00″ | 0.80″ | 1,200 | 0.76 |
S0154-JJ13 | 1/2″ | 0.59″ | 0.46″ | 6.00″ | 0.76″ | 17.00″ | 11.00″ | 1.38″ | 12.00″ | 1.00″ | 2,200 | 1.38 |
S0154-JJ16 | 5/8″ | 0.69″ | 0.63″ | 8.00″ | 0.86″ | 22.25″ | 14.50″ | 1.60″ | 16.00″ | 1.40″ | 2,800 | 2.82 |
S0154-JJ20 | 3/4″ | 0.76″ | 0.73″ | 10.00″ | 1.15″ | 27.88″ | 18.00″ | 1.74″ | 20.00″ | 1.68″ | 3,500 | 4.76 |
