Wall Mount Terminal, Hand Swage
Wall Mount Terminal, Hand Swage
Grade: 316 Stainless Steel
Retail and bulk packaging available
The Hand Swage Wall Mount is perfect for numerous marine, industrial and architectural applications. This hand swage fitting is made from grade 316 stainless steel for maximum corrosion resistance and durability and is available for cable sizes 1/8″ and 3/16″.
Specifications
ALL DIMENSIONS ARE NOMINAL (+/- 3%) AND ARE SUBJECT TO CHANGE WITHOUT NOTICE.
| ITEM | A (wire) | B | C | D | E | X | Y | Z | WT (lb) |
|---|---|---|---|---|---|---|---|---|---|
| S0723-H003 | 1/8″ | 1.51″ | 0.21″ | 1.62″ | 0.24″ | 2.16″ | 3.65″ | 0.59″ | 0.07 |
| S0723-H005 | 3/16″ | 2.01″ | 0.30″ | 1.62″ | 0.24″ | 2.16″ | 3.32″ | 0.59″ | 0.09 |
