Key Lock Spring Clip
Key Lock Spring Clip
Grade: 316 Stainless Steel
Retail and bulk packaging available
The Key Lock Spring Clip features a key lock mechanism and is made from grade 316 stainless steel for maximum corrosion resistance and durability. These stainless steel spring clips are ideal for marine and industrial applications.
Specifications
ALL DIMENSIONS ARE NOMINAL (+/- 3%) AND ARE SUBJECT TO CHANGE WITHOUT NOTICE.
| ITEM | A (size) | B | C | D | X | Y | Z | WLL (lb) | WT (lb) |
|---|---|---|---|---|---|---|---|---|---|
| S0120-K050 | 3/16″ | 0.31″ | 0.29″ | 0.20″ | 0.98″ | 2.00″ | 0.19″ | 200 | 0.04 |
| S0120-K060 | 1/4″ | 0.35″ | 0.37″ | 0.21″ | 1.20″ | 2.38″ | 0.23″ | 250 | 0.07 |
| S0120-K070 | 9/32″ | 0.46″ | 0.40″ | 0.33″ | 1.35″ | 2.88″ | 0.27″ | 300 | 0.10 |
| S0120-K080 | 5/16″ | 0.44″ | 0.43″ | 0.33″ | 1.53″ | 3.25″ | 0.31″ | 400 | 0.16 |
| S0120-K100 | 3/8″ | 0.55″ | 0.60″ | 0.40″ | 1.94″ | 4.00″ | 0.38″ | 600 | 0.30 |
| S0120-K120 | 7/16″ | 0.69″ | 0.70″ | 0.57″ | 2.19″ | 4.75″ | 0.43″ | 800 | 0.43 |
| S0120-K160 | 1/2″ | 0.87″ | 1.18″ | 0.75″ | 3.17″ | 6.38″ | 0.52″ | 1,000 | 0.78 |
