Pad Eye
Pad Eye
Grade: 304 Stainless Steel
Retail and bulk packaging available
The Pad Eye is ideal for marine, industrial, architectural, OEM and government applications. This pad eye is made from grade 304 stainless steel for maximum corrosion resistance and durability. The size is the maximum inside diameter.

Specifications


ALL DIMENSIONS ARE NOMINAL (+/- 3%) AND ARE SUBJECT TO CHANGE WITHOUT NOTICE.
ITEM | A (max diameter) | B | C | D | X | Y | Z | WLL (lb) | WT (lb) | FASTENER |
---|---|---|---|---|---|---|---|---|---|---|
S3710-0010 | 0.42″ | 0.05″ | 1.20″ | 0.15″ | 0.50″ | 1.52″ | 0.34″ | 220 | 0.01 | — |
S3710-0015 | 0.55″ | 0.08″ | 1.40″ | 0.18″ | 0.62″ | 1.84″ | 0.44″ | 230 | 0.02 | — |
S3710-0020 | 0.75″ | 0.08″ | 1.75″ | 0.19″ | 0.82″ | 2.22″ | 0.47″ | 350 | 0.03 | — |
S3710-0028 | 0.93″ | 0.09″ | 2.50″ | 0.18″ | 1.14″ | 2.94″ | 0.40″ | 250 | 0.03 | — |
S3710-0032 | 1.12″ | 0.12″ | 2.72″ | 0.22″ | 1.30″ | 3.31″ | 0.57″ | 400 | 0.05 | #14 |
